Product Details:
Payment & Shipping Terms:
|
| Name: | Touch Screen Smart Board | Resolution: | 3840 * 2160 |
|---|---|---|---|
| Android Version: | Android V8.0 | Application: | Education |
| RAM: | 4g | Working Principle: | Ultrasonic And Infrared Interactive Whiteboard |
| PC Interfaces: | HDMI Out*1;USB3.1 Gen1 Type-C*1;USB 2.0*2;USB 3.0* | Camera Pixel: | 8million Pixels |
| Feature: | Multi Finger Touch | ||
| High Light: | IR Interactive Touch Screen Smart Board,110 Inch Touch Screen Smart Board,Floor Standing Lcd Kiosk Displays |
||
Interactive Whiteboard Specification
| Touch screen | Touch technology | infrared touch screen | ||||
| Touch point | 6/10 multi-touch | |||||
| Anti light interference | The light can be illuminated with various angles and the screen can be used normally | |||||
| Writing style | Finger, pen (any opaque object with a diameter of >5MM) | |||||
| Touch accuracy | More than 95% of the touch area is + 2mm | |||||
| Communication mode | Full speed USB2.0/3.0 | |||||
| Surface hardness of writing screen | 7 grade explosion proof of physical tempered Mohs | |||||
| Touch life | The service life is more than 80000 hours | |||||
| OPS PC | CPU | Intel I3 | ||||
| Memory | Standard 4G DDR3 | |||||
| Hard disk | 2.5 inch / 7200 turn 500G | |||||
| Network card | 100/1000M Gigabit Ethernet card | |||||
| Hardware | Video input | Coaxial antenna ports: 1 | ||||
| Composite video (CVBS) input port: 2 | ||||||
| Computer VGA port: 1 (front) | ||||||
| Color difference terminals: 1 | ||||||
| HD interface (HDMI): 1 | ||||||
| MIC input | ||||||
| Touch USB input: | 1 | |||||
| Audio input: | Composite video (CVBS) audio input port: 1 | |||||
| Computer audio input interface: 1 | ||||||
| YPbPr audio port: 1 | ||||||
| Headphone audio output: 1 group | ||||||
| Special | Television system: | Image standard: PAL | ||||
| Sound system: BG, DK, I, MN | ||||||
| Decoding: 3D digital comb filter, 3D image motion noise reduction, 3D motion adaptive comb filter, etc. | ||||||
| Speaker | front speaker | |||||
| Speaker power: 10W*2 | ||||||
| Electric | Input voltage: | alternating current: 100-240V 50/60Hz | ||||
| Power: | ≤1130V | |||||
| Power saving: | <0.5W | |||||
| Environmental | relative humidity | ≤80% | ||||
| Storage humidity | -10~ +60ºC | |||||
| working temperature | 0~ +40ºC | |||||
Interactive Whiteboard​ features
♦ Ultra narrow high tensile aluminum frame with painting treatment,anti scratch and low weight.
♦ Arc plastic conner designed for kids protection.
♦ Aluminum honeycomb/ceramic board with Nanometer high molecule surface,which is smooth and anti-scracth.Water-based marker is available.
♦ Moduled PCB parts designed,easy to seperate and disassemble,easy to maintain.
♦ Power supply by USB cable,plug and play with no driver.
♦ Wall mounted and floor stand.
♦ Regular size:83"/84"/88"/92"/96"/100" with 4:3/16:9 aspect ratio choices.
♦ OEM size from 50" to 120"acceptable.
Interactive Whiteboard function
1. Common interface front, speaker front, digital audio output, support full-channel touch, touch channel automatic switching, gesture recognition, smart control, remote control integrated computer shortcut keys, smart eye protection, one-key switch;
2. Optional built-in camera, remote participants can see the scene during the network video conference;
3. Optional built-in array microphone function, during network video conference, both on-site and remote can hear the voice of each other's explanation;
4. Detachable infrared frame structure design;
5. Optional high-precision 20-point real touch with an accuracy of 1mm.
