Maystar Electronics and Electrical Industry Co.,Ltd
Big Idea Display You Future
Product Details:
Payment & Shipping Terms:
|
| Name: | Touch Screen Smart Board | Resolution: | 3840 * 2160 |
|---|---|---|---|
| Operating System: | Android & Windows | Application: | Education & Business Conference |
| RAM: | 4g | Working Principle: | Ultrasonic And Infrared Interactive Whiteboard |
| CPU: | A73 * 2 + A53 * 2 | PC Interfaces: | HDMI Out*1;USB3.1 Gen1 Type-C*1;USB 2.0*2;USB 3.0* |
| Camera Pixel: | 8 Million Pixels | Feature: | Multi Finger Touch |
| High Light: | Classroom 4G Waterproof Touch Screen Monitor,Interactive Waterproof Touch Screen Monitor,Multipoint Waterproof Touch Screen Monitor |
||
Interactive Whiteboard Specification
| Touch Panel |
Touch Technology | Infrared touch technology |
| Touch mode | Single, multipoint,Mouse click | |
| Inductive objects | Finger,pen or any other opaque objects | |
| Inductive size | Diameter≥5mm | |
| Resolution | 4096*4096 | |
| Response time | 1) First dot(click):8ms, continuously(writing):3ms 2)multipointclick:firstdot(click):8ms,continuously(writing):8ms 3) Mouse click: first dot(click):8ms,continuously(writing): 8ms |
|
| Cursor speed | UP to 300 dots/s Multipoint,mouse click:125 dot/s | |
| Operating life | ≥60,000,000 times to click | |
| Power | USB power supply (4.6-5V, DC) | |
| Power consumption | ≤1w | |
| Multi-touch operation | Compatible with windows 7 OS, to achieve the multi-touch and writingwith two points, support win7 gesture recognition |
|
| Calibration | HID devices standard, accord with Win7 multi-touch protocol, no needspecial software to calibrate, just use Table PC setting to finish thecalibration. |
|
| Anti-light decay function | Anti-light decay circuits to prevent the performance degradation causedby long working hours |
|
| LED Test Software | Supply touch screen LED test software to test the function of eachcouple of the LED lights and the drawing functions |
|
| Antilight interferencefunction | can work properly in direct sunlight condition |
Interactive Whiteboard​ Description
Interactive Whiteboard function
1. Common interface front, speaker front, digital audio output, support full-channel touch, touch channel automatic switching, gesture recognition, smart control, remote control integrated computer shortcut keys, smart eye protection, one-key switch;
2. Optional built-in camera, remote participants can see the scene during the network video conference;
3. Optional built-in array microphone function, during network video conference, both on-site and remote can hear the voice of each other's explanation;
4. Detachable infrared frame structure design;
5. Optional high-precision 20-point real touch with an accuracy of 1mm.
Details
