| Name | All In One Interactive Touch Screen Kiosk With 6mm Thickness Tempered Glass |
| Configuration 1: Android OS with Cable Network & WIFI network version |
| CMS( Content Management Software) function detail | free to set the sections. |
| |
| Configuration 2 : Windows wifi network |
| After-Sale Service Term | Warranty Period | One year of repair coverage & Lifetime complimentary support (2~3 year warranty |
| is optional) |
| Certificate& Green Management | CE | Yes |
| RoHS | Yes |
| Packaging Recyclability | All Packing material are recyclable |
| Parameter Chart for Windows wifi network |
| Main Specification | Function Version | PC Built-in Windows Operating System with Sensitive Infrared Ray Touch and Cable |
| Network+WIFI Network,LG A+ grade IPS panel and anti-vandal fully-tempered glass |
| protection, Full HD 1920*1080 2K with Wooden Box Packing |
| Panel Size | 55"(43"/49"/50"/55"/65"/75"/84" Optional) |
| Packing Material | Carton Box&EPE Inside,Wooden Box Packing Outside (Aluminium Box Is Optional) |
| Enclosure Material | High-strength Aluminium Alloy Frame,Fully High-temperred Glass,Coat Painting Strong Steel |
| Dimension | Mainbody:1930*766*55mm Base: 766*460*50mm |
| Colors | Frame: Silver Oil Painting Front : Black anti-vandal fully-temperred glass protection |
| Back: Coat Painting Strong Steel Black |
| Input Power | 110-240V/50HZ/60HZ wide range for every country |
| Power Comsuption | 138W( deponds on different function and size) |
| Operating temperature | -20 ~85℃ |
| Certificate | CE/ROHS/CB/FCC/GS/SASO/SAA/WEEE |
| Mainboard Specification | Motherboard | Intel™ Chipset ;Industrial High Class Micro ATX Form Factor; All Solid Capacitor design; |
| High Density Glass Fabric PCB ; Support Intel™ Rapid Start Technology and Smart |
| Connect Technology,10 layer gold-coating Mother board. |
| CPU | Intel™ J1900 2.0Ghz(Maximum 2.4G) with integrated Graphics Visuals; |
| (Intel™ i3/i5/i7/i9 is optional) |
| Operating System | Windows 7/Windows 10 |
| In/Out Interface Port | 2xUSB3.0,2xUSB2.0,1xHDMI,1xRJ45 Cable Network Port,1xVGA,Audio output, |
| Microphone input |
| RAM | Brand new Kingston™ or ADATA™ Dual Channel DDR3-1600 Memory Technology |
| 4G (8G/16G is optional) |
| ROM(Memory) | ADATA™/Kingston™ /Micron/Sandisk/Kingspeed High Speed Solid State Disk |
| 60/64G(128G/256G/1TB is optional) |
| WIFI Network | Included Embedded (Realtek 8111E ) |
| 3G/4G/5G Network Connectivity | Optional |
| Speaker | High Quality HD |
| Speaker Power | 2×10W (8Ω) |
| Color system | PAL/NTSC/SECAM |
| Video Format | MP4(AVI:DIVX/XVID),MPG2(DVD: VOB/MPG2),MPEG1(VCD:DAT/MPG1),WMV,MP3,MPG,TRP,TP,M2TS,TS, |
| RM,RMVB,MKV,DIVX,ASF,FLV,...etc. support all of the format of video |
| Audio Format | MP3..etc. all of the format of audio |
| Image Format | JPG,JPEG,BMP,PNG,GIF...etc, support all of the format of image |
| OSD Panel Language | English/усский/France/Español/Italian/Português/Japanese/Korean/Hebrew... |
| any all other language |
| Touch Screen Specification | Touch Point | SoftTouch sensitive Real 10 touch points (20 touch points is optional) |
| Touch Type | Latest Version Infrared Ray Touch (20 touch points Capacititve Touch is optional) |
| Touch Sensibility: | <3mm |
| Response Time | 3ms |
| Scanning Rate | 50 scans/s |
| Available object size for touch | 3mm |
| Transparency of Tempered protecting glass | >97﹪ |
| Durability of Touch | No limited |
| Surface hardness of Touch screen | Mohs 7th level ,and bearable with the hit of 6kg weight of metal ball |
| Panel Specification | Panel Brand | LG / SAMSUNG Original A+Grade IPS panel, without any light spot or black spot and Full Viewing Angle |
| Max Resolution | Full HD 1920*1080 (4K Ultra-HD 3840*2160 is available) |
| Panel color | 16.7 Millinium |
| Pixel Pitch(mm) | 0.2835(H)×0.2835(V) ~0.4833(H)×0.4833(V) |
| Brightness (nits) | 250~400cd/m2 |
| Contrast | 1500:01:00 |
| Visual angle | Full View 178/178 degreee |
| Response time | 3~5ms |
| Life(hrs) | >70,000(hrs) |
| |
| Accessories | Accessories | Qty |
| 1.User Manual | 1 |
| 2.Warranty Card | 1 |
| 3.Power Cord | 1 |
| 4.Remote Controller | 1 |
| 5.Security Door Key | 2 |
| 6.WIFI antenna | 2 |
| 7.Screw for Base | 10~12 |
| 8.Screw Driver | 1 |
